RMS Power Output – 4 Channel (14.4v):
120w x 4 @ 4 Ω stereo
175w x 4 @ 2 Ω stereo
RMS Power Output – 2 Channel Bridged Mode (14.4v):
350w x 2 @ 4 Ω
SNR:91dB (A-weighted, 20 Hz – 20 kHz)
Operating Voltage:9v – 16v
Current Draw (Music): 50 A
Current Draw (Max): 80 A
Recommended Fuse (Music):50 A
Total Efficiency: 80%
Frequency Response:20 Hz – 20 kHz +/- 3 dB
Damping Factor: 200
Crossover LPF/FULL/HPF:20 – 20kHz
Slope: 6/12/24/48 dB per octave
Gain: 0.2 V – 12 V
Turn-On Configuration:REM/DC/VOX
THD + N (10% Rated Power):0.1% @ 2 Ω per channel
Dimensions (Mounting Brackets): 5.3 x 4.9 x 2.0-inch, 134 x 125 x 51mm
Dimensions (Chassis):4.1 x 4.9 x 2.0-inch, 104 x 125 x 51mm
